| 型号： | 0009623053 |
| 厂商： | MOLEX INC |
| 元件分类： | 电路板相叠连接器 |
| 英文描述： | 5 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER, RECEPTACLE |
| 封装： | ROHS COMPLIANT |
| 文件页数： | 3/4页 |
| 文件大小： | 151K |
| 代理商： | 0009623053 |
Physical
Circuits (Loaded)
5
Flammability
94V-2
Glow-Wire Compliant
No
Lock to Mating Part
Yes
Material - Plating Mating
Gold
Material - Plating Termination
Tin
Number of Rows
1
Orientation
Vertical
PC Tail Length (in)
0.120 In
PC Tail Length (mm)
3.05 mm
PCB Locator
No
PCB Retention
None
PCB Thickness Recommended (in)
0.062 In
PCB Thickness Recommended (mm)
1.60 mm
Packaging Type
Bag
Pitch - Mating Interface (in)
0.156 In
Pitch - Mating Interface (mm)
3.96 mm
Plating min: Mating (in)
15
Plating min: Mating (m)
0.375
Plating min: Termination (in)
100
Plating min: Termination (m)
2.5
Polarized to PCB
No
Temperature Range - Operating
0°C to +75°C
Termination Interface: Style
Through Hole
Electrical(Please review the Product Specification for specific details.)
Current - Maximum per Contact
5A
Voltage - Maximum
250V
Agency Certification
UL
E29179
Solder Process Data
Duration at Max. Process Temperature
(seconds)
5
Lead-free Process Capability
Wave Capable (TH only)
Max. Cycles at Max. Process Temperature 1
Process Temperature max. C
235
Material Info
Old Part Number
A-2145-CA05A-208
Molex Connector Part Number - 0009623053
Page 3 of 4
C:\TEMP\04192010\MOLE\0009623053.mht
20-Apr-2010
