- 您现在的位置：买卖IC网 > Datasheet目录666 > A8W RUBBER CAP (Omron Electronics Inc-EMC Div)SWITCH ROCKER RUBBER CAP Datasheet资料下载
参数资料
| 型号： | A8W RUBBER CAP |
| 厂商： | Omron Electronics Inc-EMC Div |
| 文件页数： | 2/3页 |
| 文件大小： | 0K |
| 描述： | SWITCH ROCKER RUBBER CAP |
| 标准包装： | 100 |
| 附件类型： | 摇臂套 |
| 适用于相关产品： | A8W 系列 |
| 配用： | A8WS-2263-ND - SWITCH ROCKER MINI SPST 16A WHT A8WS-2262-ND - SWITCH ROCKER MINI SPST 16A WHT A8WS-1163-ND - SWITCH ROCKER MINI SPST 16A BLCK A8WS-1162-ND - SWITCH ROCKER MINI SPST 16A BLCK A8WD-2263-ND - SWITCH ROCKER MINI DPST 16A WHT A8WD-2262-ND - SWITCH ROCKER MINI DPST 16A WHT A8WD-1163-ND - SWITCH ROCKER MINI DPST 16A BLCK A8WD-1162-ND - SWITCH ROCKER MINI DPST 16A BLCK |
| 其它名称： | A8WRUBBERCAP |
A8W
A8W
■ Dimensions
A8WS-1162
A8WS-1163
A8WS-2262
(Unit: mm)
Note: The following illustrations and drawings are for 2 poles (DPST) models,
1 pole (SPST) models have single side terminals.
● Operating Characteristics
A8WS-2263
No. of poles
1 (SPST)
2 (DPST)
A8WD-1162
17
Operating force (OF) max.
12 N {1,224 gf}
23 N {2,345 gf}
A8WD-1163
A8WD-2262
A8WD-2263
15.6
-0.5
24 +0.3
10.6
2
5.3 ± 0.5
17.5
2.8 dia.
25.8
3.8
2.1
1.6 dia.
9.6
0.8
17.9
21.5
Solder Terminal
10
12.4
14.4
14.8
#250 Quick connect terminal (t=0.8) common use
Quick-connect Terminals are not in compliance with IEC standards.
Note: Unless otherwise specified, a tolerance of ±0.3 mm applies to all dimensions.
■ Panel Cutout
X
Y
Panel thickness (mm)
X (mm)
Y (mm)
Without rubber
1.0 to 1.9
22.3
+0.1
0
cap
2.0 to 2.8
23.2 +0.1
14.8 +0.1
With rubber cap
2.0
0
-0.07
22.4
+0.1
0
R0.3 ± 0.1
Edge
Process the above-mentioned R on the
mounting hole side of panel, or be sure that the
Play R is on the operation side of panel when
using.
Be sure that the Edge is on the reverse side of
panel when processing.
2
