参数资料
| 型号： | ACT4445 |
| 元件分类： | 网络接口 |
| 英文描述： | DATACOM, MIL-STD-1553 DATA BUS TRANSCEIVER, BCC64 |
| 封装： | BCC-64 |
| 文件页数： | 7/9页 |
| 文件大小： | 180K |
| 代理商： | ACT4445 |
7
SCD4445 Rev B
PACKAGE PIN OUT DESCRIPTION - ACT4445
Pin #
Function
Pin #
Function
1NC
33
NC
2
OUTCOMP 1
34
NC
3
CURSUM1
35
RXOUT 1
4
BASE 1i
36
RXOUT 1 IN
5BASE 1
37
RX GND
6
TXOUT 1
*
38
DC2 - 12
7
TXOUT 1
*
39
DC2 - 15
8
VCCTX
*
40
VL RX
9
VCCTX
*
41
DC1 - 15
10
TXOUT 2
*
42
DC1 - 12
11
TXOUT 2
*
43
COMP 1
12
BASE 2
44
COMP 2
13
BASE 2i
45
NC
14
CURSUM 2
46
NC
15
OUTCOMP 2
47
NC
16
NC
48
FIL 2
17
NC
49
NC
18
TX GND 2
50
FIL 1
19
INTCOMP 2
51
RXBYPASS
20
EM2 OUT
52
RXN IN
21
EM2 IN
53
RX IN
22
IEXOR 2
54
NC
23
R ISET
55
VEERX
24
TX GND 5V
56
INHIBIT
25
VL TX
57
TXN IN
26
1NH
58
TX IN
27
1NL
59
IEXOR 1
28
2 NL
60
EM1 IN
29
2 NH
61
EM1 OUT
30
STROBE
62
INTCOMP 1
31
RXOUT 2 IN
63
TX GND 1
32
RXOUT 2
64
NC
NC = No Connect
* High Current Line (~100mA)
