APTM100VDA35T3G
APTM100VDA35
T
3G–
Rev
0
Septem
ber,
2009
www.microsemi.com
3 – 7
Thermal and package characteristics
Symbol
Characteristic
Min
Typ
Max
Unit
Transistor
0.32
RthJC
Junction to Case Thermal Resistance
Chopper diode
1.2
°C/W
VISOL
RMS Isolation Voltage, any terminal to case t =1 min, I isol<1mA, 50/60Hz
4000
V
TJ
Operating junction temperature range
-40
150
TSTG
Storage Temperature Range
-40
125
TC
Operating Case Temperature
-40
100
°C
Torque Mounting torque
To heatsink
M4
2.5
4.7
N.m
Wt
Package Weight
110
g
Temperature sensor NTC (see application note APT0406 on www.microsemi.com for more information).
Symbol
Characteristic
Min
Typ
Max
Unit
R25
Resistance @ 25°C
50
k
Ω
R25/R25
5
%
B25/85
T25 = 298.15 K
3952
K
B/B
TC=100°C
4
%
=
T
B
R
T
1
exp
25
85
/
25
SP3 Package outline (dimensions in mm)
17
12
28
1
See application note 1901 - Mounting Instructions for SP3 Power Modules on www.microsemi.com
T: Thermistor temperature
RT: Thermistor value at T
