PICDEM? LCD Demonstration Kit User’s Guide
A.1
A.2
A.3
A.4
A.5
A.6
A.7
PROCESSORS
On-board PIC18F8490 (U1) is provided with the daughter board option (U1A) for other
PIC18FXX90 and PIC16C92X devices, Microchip’s future LCD parts and ICE. A slide
switch (S7) is provided to select either the on-board device or the device on the
daughter board.
LCD DISPLAY
An 8-digit starburst LCD display with 14 segments each is provided. This LCD has
4 commons and 32 segments.
In PICDEM LCD, the user can use any LCD glass by:
? Removing jumpers COM0, COM1, COM2 and COM3.
? Connecting the LCD glass on J2.
LED DISPLAY
Two green LEDs are connected to RB0 and RB5 of U1 and U1A. These LEDs may be
disconnected from RB0 and RB5 by removing jumpers JP3 and JP4.
One green LED is provided to determine whether there is power to the LCD
Demonstration Board (LED on) or not (LED off).
OSCILLATOR
The on-board firmware uses the internal RC oscillator running at 8 MHz.
? Internal RC oscillator running at 8 MHz can be used.
? Pads provided for user-furnished crystal/resonator (Y2) and two capacitors
(C16 and C17).
? Socket provided for a canned oscillator (Y3). This oscillator can be disabled by
removing jumpers JP9, JP11 and JP12.
? 32.768 kHz (watch-type) crystal for Timer1 (Y1). This oscillator can be disabled by
removing jumpers JP7 and JP8.
RS-232 SERIAL PORT
An RS-232 level shifting IC has been provided with all necessary hardware to support
connection of an RS-232 host through the DB9 connector (PI). The port is configured
as DCE and can be connected to a PC using a serial cable.
REAL-TIME CLOCK
This circuit allows the user to configure a PICmicro MCU for timekeeping using a
32.768 kHz clock crystal connected to Timer1’s T1OSO and T1OSI pins.
SERIAL EEPROM
A socket for a Microwire EEPROM is provided on the board to illustrate usage of
the Synchronous mode of operation of the USART module. For its operation:
? Jumpers JP15 and JP16 should be connected.
? In the jumper J6, U9-CS should be connected with RB5.
? In the jumper J13, U9-ORG should be connected to GND.
DS51536A-page 21
? 2005 Microchip Technology Inc.
