PRODUCT SPECIFICATION
FMS6414
4
REV. 1.0.1 6/27/02
Absolute Maximum Ratings (beyond which the device may be damaged)
Note: Functional operation under any of these conditions is NOT implied. Performance and reliability are guaranteed only if
Operating Conditions are not exceeded.
Operating Conditions
Parameter
Min
Max
Units
VCC_VIDEO (Positive DC Supply Voltage)
+6.5
V
GND_VIDEO (Negative DC Supply Voltage)
V
Analog and Digital I/O
GND – 0.3
VCC + 0.3
V
Output Current (Continuous)
60
mA
Junction Temperature
150
°C
Storage Temperature Range
-65
+150
°C
Lead Temperature (Soldering, 10s)
260
°C
Thermal Resistance (
Θ
JA)
115
°C/W
Parameter
Min
Typ
Max
Units
Temperature Range
0
70
°C
VCC_VIDEO Range
4.75
5.0
5.25
V
GND_VIDEO
0
V
ICC (+5 VDC)
60
mA
