HELIAX
Connector
P R O D U C T
S P E C I F I C A T I O N
7/16 DIN for LDF4-50A, Low Density Foam Dielectric Cable
L4PDF
Electrical
Average Power, max, kW @ 900 MHz
Cable Limited
1.11
dc Test Maximum Voltage
4,000
Connector Limited
RF Operating Voltage, max, VRMS
1,415
Connector Limited
1,980
Connector Limited
RF High Potential, max, VRMS
Inner Contact Resistance
0.80
MilliOhms
Outer Contact Resistance
MilliOhms
1.50
3rd Order IM, Product Typical @ 910 MHz, -dBm
-120
3rd Order IM Test Method
Two +43 dBm Carriers
50
Nominal Impedence, Ohms
50
Cable Impedence, Ohms
Insertion Loss, max, dB
frequency(GHz)
0.05
Connector Return Loss, dB
0 - 0.88 GHz
35
0.88 - 1.8 GHz
32
1.8 - 2.6 GHz
28
2.6 - 3.5 GHz
26
Mechanical
Inner Attachment Method
Solder
Outer Attachment Method
Self flare
Pressurizable
No
Coupling Nut Retention Force, N (lb)
1,000.0 (224.8)
Method
MIL-C-39012C 3.25, 4.6.22
Minimum Coupling Nut Torque, N-m (lb-in)
25.0 (221.3)
Minimum Connector Retention Tensile Force, N (lb)
890.0 (200.1)
Minimum Connector Retention Torque, N-m (lb-in)
5.4 (47.8)
Attachment Durability (Number of cycles)
25
Interface Durability (Number of cycles)
50
Environmental
Corrosion Test
IEC 68, part 2-11, Test Ka
Vibration Test
IEC 68, Part 2-6
Operating Temperature Range, °C
-40 to 85
Storage Temperature Range, °C
-40 to 85
Customer Support Center:
From North America: 1-800-255-1479
International: +1-708-873-2307
www.andrew.com
This Specification Sheet is for reference only and is subject to change without notice.
Copyright 2002 by Andrew Corporation, Printed in U.S.A.
March 05, 2002
