HELIAX
Connector
P R O D U C T
S P E C I F I C A T I O N
7/16 DIN for LDF4RN-50A, Low Density Foam Dielectric
Cable
L4PDM
Recommended Maximum Operating Frequency, GHz
5.2
Connector Limited
Peak Power, max, kW
Connector Limited
40.0
Average Power, max, kW @ 900 MHz
Cable Limited
1.11
dc Test Maximum Voltage
4,000
Connector Limited
RF Operating Voltage, max, VRMS
1,415
Connector Limited
1,980
RF High Potential, max, VRMS
Inner Contact Resistance
0.80
MilliOhms
Outer Contact Resistance
MilliOhms
1.50
3rd Order IM, Product Typical @ 910 MHz, -dBm
-120
3rd Order IM Test Method
Two +43 dBm Carriers
Insulation Resistance, min, MOhms
5,000
Connector Limited
Shielding Effectiveness, dB
-110
50
Nominal Impedence, Ohms
50
Cable Impedence, Ohms
Insertion Loss, max, dB
frequency(GHz)
0.05
Connector Return Loss, dB
0 - 1 GHz
42
1 - 4.2 GHz
35
4.2 - 5 GHz
33
5 - 5.2 GHz
25
Mechanical
Inner Attachment Method
Solder on
Outer Attachment Method
Self flare
Connector Weight, kg (lb)
0.270 (0.595)
Pressurizable
No
Coupling Nut Retention Force, N (lb)
1,000.0 (224.8)
Method
MIL-C-39012C 3.25, 4.6.22
Minimum Coupling Nut Torque, N-m (lb-in)
25.0 (221.3)
Insertion Force, N (lb)
100.1 (22.5)
Method
MIL-C-39012C 3.5, 4.6.2
Minimum Connector Retention Tensile Force, N (lb)
890.0 (200.1)
Minimum Connector Retention Torque, N-m (lb-in)
5.4 (47.8)
Attachment Durability (Number of cycles)
25
Interface Durability (Number of cycles)
50
Environmental
Corrosion Test
IEC 68, part 2-11, Test Ka
Vibration Test
IEC 68, Part 2-6
Operating Temperature Range, °C
-40 to 85
Storage Temperature Range, °C
-40 to 85
Customer Support Center:
From North America: 1-800-255-1479
International: +1-708-873-2307
www.andrew.com
This Specification Sheet is for reference only and is subject to change without notice.
Copyright 2002 by Andrew Corporation, Printed in U.S.A.
December 19, 2001
