| 型号： | MPC8315E-RDB |
| 厂商： | Freescale Semiconductor |
| 文件页数： | 2/2页 |
| 文件大小： | 0K |
| 描述： | PROCESSOR BOARD PWRQUICCII PBGA |
| 产品培训模块： | MPC8314/15 Product Overview |
| 标准包装： | 1 |
| 系列： | PowerQUICC II™ PRO |
| 类型： | MPU |
| 适用于相关产品： | MPC8315E |
| 所含物品： | 参考设计板、软件和说明文档 |
Features
? CPU: Freescale MPC8315E running at
400/266 MHz (CPU/DDR2)
? Ethernet
Two Gigabit RGMII connections directly
to PHY
One Ethernet connection to broadband
powerline capability using DS2
? PCI Express
PCI Express add-in connector
MiniPCI Express for WLAN
? SATA
Two standard SATA connectors
eSATA will be available through
SATA-eSATA connectors
? SPI/TDM
Connected to dual Legerity SLIC/SLAC
? I 2 C
Connected to real-time clock
May be eliminated using the MCU
? Dual UART
Connectors for debug connectivity
? Local bus
NAND flash/NOR flash memory
? High speed
Connector directly on board
3-port USB hub
? PCI
One standard and one
MiniPCI connector
? Memory
32-bit DDR2 with population option
for 16-bit
Extra header (compliant to MPC832x RDB)
for Bluetooth ? /ZigBee ? future connectivity
MPC8315E-RDB Block Diagram
Security
Acceleration
e300 Core
16 KB 16 KB
L1 I-Cache L1 D-Cache
Performance Monitor,
DUART, I 2 C,
Timers, GPIO,
Interrupt Control
I 2 C Bus 2
I 2 C Bus 1
UART2
UART1
TDM
System Bus
DDR/DDR2
SDRAM Controller
Local Bus
SPI
32-bit DDR2
8 x NAND
K9F5608U8D
16 x NOR
2 x Gigabit
Ethernet
2 x PCI
Express ?
PCI
2x
SATA
4-ch.
DMA
USB
+ PHY
MX29LV640
2-lane SerDes
MCU
MC9S08QG8
RGMII/
ULPI
RGMII
2 x SLIC/SLAC
2 x 8P8C RJ-45
MiniPCI Socket
2 x Type L SATA
4 x USB
2 x RS-232
PS/2 Connector
Connector
NTSC/PAL + DV-25
Tuner Interface
Expansion Card
xDSL/Power Line
Network Module
Core
Accelerators
I/O
Connector or Slot
Learn More:
For current information about Freescale
products and documentation, please visit
www.freescale.com/storage .
Freescale and the Freescale logo are trademarks or registered trademarks of Freescale Semiconductor, Inc.
in the U.S. and other countries. All other product or service names are the property of their respective owners.
The Power Architecture and Power.org word marks and the Power and Power.org logos and related marks are
trademarks and service marks licensed by Power.org. ? Freescale Semiconductor, Inc. 2009.
Document Number: MPC8315ERDBFS
REV 2
