参数资料
| 型号： | PC451TJ0000F |
| 厂商： | Sharp Microelectronics |
| 文件页数： | 11/14页 |
| 文件大小： | 0K |
| 描述： | PHOTOCOUPLER HI VCE TRAN 4-SMD |
| 标准包装： | 750 |
| 通道数： | 1 |
| 输入类型： | DC |
| 电压 - 隔离： | 3750Vrms |
| 电流传输比（最小值）： | 40% @ 5mA |
| 输出电压： | 350V |
| 电流 - 输出 / 通道： | 50mA |
| 电流 - DC 正向(If)： | 50mA |
| Vce饱和（最大）： | 300mV |
| 输出类型： | 晶体管 |
| 安装类型： | 表面贴装 |
| 封装/外壳： | 4-SMD |
| 包装： | 带卷 (TR) |
PC451J00000F Series
● Cleaning instructions
Solvent cleaning:
Solvent temperature should be 45?C or below Immersion time should be 3 minutes or less
Ultrasonic cleaning:
The impact on the device varies depending on the size of the cleaning bath, ultrasonic output, cleaning time,
size of PCB and mounting method of the device.
Therefore, please make sure the device withstands the ultrasonic cleaning in actual conditions in advance of
mass production.
Recommended solvent materials:
Ethyl alcohol, Methyl alcohol and Isopropyl alcohol
In case the other type of solvent materials are intended to be used, please make sure they work fine in
actual using conditions since some materials may erode the packaging resin.
● Presence of ODC
This product shall not contain the following materials.
And they are not used in the production process for this product.
Regulation substances : CFCs, Halon, Carbon tetrachloride, 1.1.1-Trichloroethane (Methylchloroform)
Specific brominated flame retardants such as the PBBOs and PBBs are not used in this product at all.
This product shall not contain the following materials banned in the RoHS Directive (2002/95/EC).
?Lead, Mercury, Cadmium, Hexavalent chromium, Polybrominated biphenyls (PBB), Polybrominated
diphenyl ethers (PBDE).
Sheet No.: D2-A00302EN
11
