- 您现在的位置：买卖IC网 > PDF目录40402 > SSCDA2 (SENSITRON SEMICONDUCTOR) 8 A, SILICON, RECTIFIER DIODE PDF资料下载
参数资料
| 型号： | SSCDA2 |
| 厂商： | SENSITRON SEMICONDUCTOR |
| 元件分类： | 整流器 |
| 英文描述： | 8 A, SILICON, RECTIFIER DIODE |
| 封装： | 407, 3 PIN |
| 文件页数： | 1/2页 |
| 文件大小： | 107K |
| 代理商： | SSCDA2 |
Center Tap / Doubler Assembly
PART NUMBER:SSCDA2
PACKAGE STYLE:407
CONFIGURATION:Center Tap / Doubler Assembly
DESCRIPTION:200 VOLT, 8 AMP, 5000 NANOSECOND Center Tap / Doubler Assembly RECTIFIER ASSEMBLY
-All ratings are at TA =25°C unless otherwise specified
Disclaimer
MAXIMUM RATINGS / ELECTRICAL CHARACTERISTICS
RATING
CONDITIONS
MIN TYP MAX UNITS
PEAK INVERSE VOLTAGE (PIV)
-
200
Vdc
AVERAGE DC OUTPUT CURRENT (I
O)
T
C=55°C
T
C=100°C
-
8
6
Amps
PEAK SINGLE CYCLE SURGE CURRENT
(I
fsm)
T
p=8.3 ms Single Half Cycle Sine Wave,
Superimposed On Rated Load
-
150
Amps
(pk)
OPERATING AND STORAGE TEMP. (T
OP
& T
stg)
-
-55
-
+150
°C
MAXIMUM FORWARD VOLTAGE (V
f)
I
f =3.0A (300 msec pulse, duty cycle<2%)
-
1.4 @
9
Volts
MAXIMUM INSTANTANEOUS REVERSE
CURRENT AT RATED (PIV)
T
A=25°C
T
A=100°C
-
5
100
mAmps
REVERSE RECOVERY TIME (t
rr)
I
f=0.5A, Ir=1.0A, Irr=0.25A
-
5000
nsec
THERMAL RESISTANCE
-
4
°C/W
Data and specifications subject to change without notice.
Page 1 of 2
Single Phase Full Wave Bridge Rectifier Assemblies Web Site Template
11/29/2007
http://www.sensitron.com/CTDA_item.asp?type=SSCDA2&groupid=CTD
