3/7
LIS2L02AS4
ELECTRICAL CHARACTERISTCS (Temperature range -40°C to +85°C)
All the parameters are specified @ Vdd=3.3V and T=25°C unless otherwise noted
Notes: 1. Typical specifications are not guaranteed
2. Guaranteed by wafer level test and measurement of initial offset and sensitivity
3. Bandwidth=1/(2*
π*100K*Cload)
Symbol
Parameter
Test Condition
Min.
Typ.1
Max.
Unit
Vdd
Supply voltage
2.4
5.25
V
Idd
Supply current
850
A
Voff
Zero-g level
T = 25°C
ratiometric to Vdd
Vdd/2-18%
Vdd/2
Vdd/2+18%
V
Ar
Acceleration range2
0V on FS pin
±1.8
±2.0
±2.2
g
Vdd on FS pin
±6.0
g
So
Sensitivity ratiometric to Vdd
T = 25°C
Full-scale = 2g
Vdd/5–10%
Vdd/5
Vdd/5+10%
V/g
T = 25°C
Full-scale = 6g
Vdd/15–10%
Vdd/15
Vdd/15+10%
V/g
NL
Non Linearity
Best fit straight line
X, Y axis
Full-scale = 2g
±1% FS
fuc
Sensing Element Resonant
Frequency
X, Y axis
4.0
KHz
an
Acceleration noise density
Vdd=5V
Full-scale = 2g
50
g/
Vt
Self test output voltage
Ratiometric to Vdd
T = 25°C
Vdd=3.3V
27
mV
T = 25°C
Vdd=5V
95
mV
Vst
Self test input
Logic 0 level
0
0.8
V
Logic 1 level
2.8
Vdd
V
Rout
Output impedance
100
k
Cload
Capacitive load drive3
320
pF
Hz
