Z-Power
LED
X10490
Z-Power
LED
X10490
Technical
Data
Sheet
Rev. 1.00
December 2009
www.acriche.com
Document No. : SSC-QP-7-07-24 (Rev.00)
0/50
10 cycle
25℃ ~ 65℃ ~ -10℃
TH = 90%, 24 hr / 1 cycle
JEITA ED-4701
200 203
Moisture
Resistance Cycle
0/50
100 cycle
-40℃ ~ 25℃ ~ 100℃ ~ 25℃
(30min) (5min) (30min) (5min)
JEITA ED-4701
100 105
Temperature Cycle
0/50
1 times
over 95%
Tsld = 215±5℃, 3 sec
(Lead Solder)
JEITA ED-4701
303
Solder ability
(Reflow Soldering)
0/50
2 times
Tsld = 260℃, 10 sec
pre treatment ; 30℃, 70%, 168hrs
JEITA ED-4701
301 302
Resistance to
Soldering Heat
testing
500
Hours
T
a = 60℃, RH = 90%, IF = 20mA
JEITA ED-4701
100 102
High Humidity
Heat Life Test
testing
1,000
Hours
T
a = 85℃, RH = 85%
JEITA ED-4701
100 103
Humidity Heat
Load
testing
1,000
Hours
T
a = -40℃
JEITA ED-4701
200 202
Low Temperature
Storage
0/50
20 Cycle
T
a = -30℃ (30MIN) ~ 85℃ (30MIN)
JEITA ED-4701
300 307
Thermal Shock
testing
1,000
Hours
T
a = 85℃, IF = 5mA
-
High Temperature
Life Test
testing
1,000
Hours
T
a = -30℃, IF = 20mA
-
Low Temperature
Life Test
testing
500
Hours
T
a = 25℃, IF = 30mA
JEITA ED-4701
100 101
Life Test 2
testing
1,000
Hours
T
a = 100℃
JEITA ED-4701
200 201
High Temperature
Storage
testing
1,000
Hours
T
a = 25℃, IF = 20mA
JEITA ED-4701
100 101
Life Test 1
Number of
Damage
Duration
/ Cycle
Test Condition
Reference
Item
-
LSL*2 × 0.5
I
F =20mA
I
V
Luminous Intensity
USL × 2.0
-
V
R=5V
I
R
Reverse Current
USL*1 × 1.2
-
I
F =20mA
V
F
Forward Voltage
MAX
MIN
Criteria for Judgement
Condition
Symbol
Item
Note : *1 USL : Upper Standard Level
*2 LSL : Lower Standard Level
* Criteria for Judging the Damage
5. Reliability Test
* TEST ITEMS AND RESULTS
