参数资料
| 型号： | CMPWR330SF |
| 厂商： | ON Semiconductor |
| 文件页数： | 1/10页 |
| 文件大小： | 0K |
| 描述： | IC REG LDO 3.3V .4A SOIC8 |
| 产品变化通告： | Product Discontinuation 30/Sept/2011 |
| 标准包装： | 2,500 |
| 系列： | SmartOR™ |
| 稳压器拓扑结构： | 正，固定式 |
| 输出电压： | 3.3V |
| 输入电压： | 最高 5.25V |
| 稳压器数量： | 1 |
| 电流 - 输出： | 400mA（最小值） |
| 工作温度： | 0°C ~ 70°C |
| 安装类型： | 表面贴装 |
| 封装/外壳： | 8-SOIC（0.154"，3.90mm 宽） |
| 供应商设备封装： | 8-SOICN |
| 包装： | 带卷 (TR) |
CMPWR330
400 mA SmartOR t Regulator
with V AUX Switch
Product Description
The CMPWR330 is a dual input regulator with a fully integrated
V AUX switch capable of delivering up to 400 mA continuously at
3.3 V. The input is taken from three independent voltage sources on
a prioritized basis. Power is always taken in priority using the order of
V CC, V SBY , and V AUX .
When V CC , (5 V) or V SBY is present, the device automatically
enables the regulator and produces a stable 3.3 V output at V OUT .
When only V AUX (3.3 V) is present, the device provides a low
impedance direct connection (0.25 W TYP.) from V AUX to V OUT .
All the necessary control circuitry needed to provide a smooth and
automatic transition between all three supplies has been incorporated.
This allows the V CC input supply to be dynamically switched without
loss of output voltage.
The CMPWR330 is housed in an 8 ? pin SOIC package and is
available with RoHS compliant lead ? free finishing.
Features
? Continuous 3.3 V Output from Three Inputs
? Complete Power Management Solution
? V CC , V SBY Regulator Supplies 400 mA Output
? Built ? In Hysteresis when Selecting Input Supplies
? Integrated Switch Has Very Low R DS(ON) Resistance of 0.25 W
(TYP)
? Foldback Current Limiting Protection
? Thermal Overload Shutdown Protection
? 8 ? Pin Power SOIC Package
? These Devices are Pb ? Free and are RoHS Compliant
Applications
? PCI Adapter Cards with Wake ? On ? LAN
? Network Interface Cards (NICs)
? Multiple Power Systems
? Systems with Standby Capabilities
http://onsemi.com
SIOC 8
SF SUFFIX
CASE 751BD
MARKING DIAGRAM
CMPWR330SF
CMPWR330SF = Specific Device Code
ORDERING INFORMATION
Device Package Shipping ?
CMPWR330SF Power SOIC 750/Tape & Reel
(Pb ? Free)
?For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specification
Brochure, BRD8011/D.
? Semiconductor Components Industries, LLC, 2011
April, 2011 ? Rev. 4
1
Publication Order Number:
CMPWR330/D
