Getting Started
Setting Up The Development System
5. Switch Power switch to on
Power and ready LED lights after the base station finished start-up sequence.
There are three status LEDs on the box: busy, ready, and error. The FSICEBASE base
station takes about 5-10 seconds to start up. After powering the unit, you must wait for the
ready LED to light before attempting to communicate.
The FSICEBASE is now ready to accept communication with a host computer. You will
need to install the CodeWarrior software, create a project, and start the debugger to
establish communication between your host computer and the FSICEBASE.
Installing CodeWarrior Software
The software portion of the development system consists of two parts. One part is the
CodeWarrior Development Studio for HC(S)08 v3.1, which does not contain support for
the FSICEBASE. The other part is a software patch that adds support to the CodeWarrior
software Development Studio for HC(S)08 v3.1 for the FSICEBASE. This software patch
is only required for CodeWarrior fDevelopment Studio for HC(S)08 v3.1. The following
procedure explains how to install both pieces of software.
To install the CodeWarrior software on your host computer:
1. Install CodeWarrior IDE
a. Insert CodeWarrior Development Studio CD into CD-ROM drive — CW Auto
Install begins
NOTE
If Auto Install does not start, run launch.exe, which is located in the root
directory of the CD.
b. Follow setup program's on-screen instructions
2. Restart your computer — operating system reboots which ensures that CodeWarrior
IDE finds newly installed drivers
3. Launch CodeWarrior IDE
a. Select Start > Programs > Metrowerks CodeWarrior >
CW08 V3.1 — menu appears
b. Select CodeWarrior IDE — IDE starts; main window appears
4. Register CodeWarrior software
Freescale In-Circuit Emulator Base User Manual, Rev. 1.1
Freescale Semiconductor
17
