MAXQ2000
Low-Power LCD Microcontroller
____________________________________________________________________
11
Pin Description (continued)
PIN
TQFN-EP
QFN-EP
LQFP
NAME
FUNCTION
General-Purpose, Digital, I/O, Type-D Port; LCD Segment-Driver Output; External
Edge-Selectable Interrupt. This port functions as both bidirectional I/O pins and
LCD segment-drive outputs. All port pins are defaulted as input with weak pullup
after a reset. The port pads can be configured as an external interrupt for pins 7 to
4. If the external interrupt is enabled, the LCD function on the associated pin is
disabled. Setting the PCF0 bit enables the LCD for all pins on this port and disables
the general-purpose I/O function on all pins.
It is possible to mix the LCD and interrupt functions on the same port. To do this,
the interrupt enable must be established prior to setting the PCF0 bit. Care must be
taken not to enable the external interrupt while the LCD is in normal operational
mode, as this could result in potentially harmful contention between the LCD
controller output and the external source connected to the interrupt input.
56-PIN
68-PIN
100-PIN
PORT
ALTERNATE FUNCTIONS
49
58
89
P0.0
SEG0
—
50
59
90
P0.1
SEG1
—
51
60
91
P0.2
SEG2
—
52
61
92
P0.3
SEG3
—
53
62
93
P0.4
SEG4
INT0
54
63
94
P0.5
SEG5
INT1
55
64
95
P0.6
SEG6
INT2
49–56
58–65
89–96
P0.0–
P0.7;
SEG0–
SEG7;
INT0–
INT3
56
65
96
P0.7
SEG7
INT3
—
1, 2, 12,
13, 24,
25, 26,
35, 37,
38, 44–
49, 51,
55, 61,
72–75,
77–80,
87, 88,
99, 100
N.C.
No Connection. These pins should not be connected.
—
EP
Exposed Paddle. Exposed paddle is on the under side of the package. It should be
left unconnected.
