参数资料
| 型号： | IXTP100N04T2 |
| 厂商： | IXYS |
| 文件页数： | 2/6页 |
| 文件大小： | 0K |
| 描述： | MOSFET N-CH 40V 100A TO-220 |
| 产品目录绘图： | TO-220, TO-251 |
| 标准包装： | 50 |
| 系列： | TrenchT2™ |
| FET 型： | MOSFET N 通道，金属氧化物 |
| FET 特点： | 标准 |
| 漏极至源极电压(Vdss)： | 40V |
| 电流 - 连续漏极(Id) @ 25° C： | 100A |
| 开态Rds（最大）@ Id, Vgs @ 25° C： | 7 毫欧 @ 25A，10V |
| Id 时的 Vgs(th)（最大）： | 4V @ 250µA |
| 闸电荷(Qg) @ Vgs： | 25.5nC @ 10V |
| 输入电容 (Ciss) @ Vds： | 2690pF @ 25V |
| 功率 - 最大： | 150W |
| 安装类型： | 通孔 |
| 封装/外壳： | TO-220-3 |
| 供应商设备封装： | TO-220 |
| 包装： | 管件 |
IXTA100N04T2
IXTP100N04T2
Symbol Test Conditions
(T J = 25 ° C, unless otherwise specified)
Characteristic Values
Min. Typ. Max.
TO-263 (IXTA) Outline
g fs
C iss
C oss
C rss
t d(on)
t r
t d(off)
t f
Q g(on)
Q gs
Q gd
V DS = 10V, I D = 0.5 ? I D25 , Note 1
V GS = 0V, V DS = 25V, f = 1MHz
Resistive Switching Times
V GS = 10V, V DS = 20V , I D = 0.5 ? I D25
R G = 5 Ω (External)
V GS = 10V, V DS = 0.5 ? V DSS , I D = 0.5 ? I D25
27
45
2690
490
105
12.0
5.2
15.8
6.4
25.5
8.0
5.7
S
pF
pF
pF
ns
ns
ns
ns
nC
nC
nC
R thJC
1.0 ° C/W
R thCH
TO-220
0.50
° C/W
Source-Drain Diode
Symbol Test Conditions
(T J = 25 ° C, unless otherwise specified)
Characteristic Values
Min. Typ. Max.
I S
V GS = 0V
100
A
I SM
V SD
t rr
I RM
Q RM
Repetitive, Pulse width limited by T JM
I F = 50A, V GS = 0V, Note 1
I F = 50A, V GS = 0V
-di/dt = 100A/ μ s
V R = 20V
34
1.44
24.5
400
1.2
A
V
ns
A
nC
TO-220 (IXTP) Outline
Notes: 1. Pulse test, t ≤ 300 μ s; duty cycle, d ≤ 2%.
2. On through-hole packages, R DS(on) Kelvin test contact
location must be 5mm or less from the package body.
PRELIMINARY TECHNICAL INFORMATION
The product presented herein is under development. The Technical Specifications offered are derived
from data gathered during objective characterizations of preliminary engineering lots; but also may yet
contain some information supplied during a pre-production design evaluation. IXYS reserves the right
to change limits, test conditions, and dimensions without notice.
IXYS reserves the right to change limits, test conditions, and dimensions.
Pins:
1 - Gate
3 - Source
2 - Drain
4 - Drain
IXYS MOSFETs and IGBTs are covered
4,835,592
4,931,844
5,049,961
5,237,481
6,162,665
6,404,065 B1
6,683,344 6,727,585 7,005,734 B2
7,157,338B2
by one or more of the following U.S. patents: 4,850,072
5,017,508
5,063,307
5,381,025
6,259,123 B1
6,534,343
6,710,405 B2 6,759,692 7,063,975 B2
4,881,106
5,034,796
5,187,117
5,486,715
6,306,728 B1
6,583,505
6,710,463
6,771,478 B2 7,071,537
