参数资料
| 型号： | CMPWR150SF |
| 厂商： | ON Semiconductor |
| 文件页数： | 3/10页 |
| 文件大小： | 0K |
| 描述： | IC REG LDO 3.3V .5A SOIC8 |
| 产品变化通告： | Product Discontinuation 30/Sept/2011 |
| 标准包装： | 2,500 |
| 系列： | SmartOR™ |
| 稳压器拓扑结构： | 正，固定式 |
| 输出电压： | 3.3V |
| 输入电压： | 4.5 V ~ 5.5 V |
| 稳压器数量： | 1 |
| 电流 - 输出： | 500mA（最小值） |
| 电流 - 限制（最小）： | 500mA |
| 工作温度： | 0°C ~ 70°C |
| 安装类型： | 表面贴装 |
| 封装/外壳： | 8-SOIC（0.154"，3.90mm 宽） |
| 供应商设备封装： | 8-SOICN |
| 包装： | 带卷 (TR) |
CMPWR150
SPECIFICATIONS
Table 2. ABSOLUTE MAXIMUM RATINGS
Parameter
ESD Protection (HBM)
Pin Voltages
V CC
DRIVE
Storage Temperature Range
Operating Temperature Range
Ambient
Junction
Power Dissipation
SOIC (Note 1)
Rating
± 2000
[GND ? 0.5] to [+6.0]
[GND ? 0.5] to [V CC + 0.5]
? 40 to +150
0 to +70
0 to +125
1.0
Units
V
V
° C
° C
W
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the
Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect
device reliability.
1. The SOIC package used is thermally enhanced through the use of a fused integral leadframe. The power rating is based on a printed circuit
board heat spreading capability equivalent to 2 square inches of copper connected to the GND pins. Typical multi ? layer boards using power
plane construction will provide this heat spreading ability without the need for additional dedicated copper area. (Please consult factory for
thermal evaluation assistance.)
Table 3. STANDARD OPERATING CONDITIONS
Parameter
V CC Input Voltage
Ambient Operating Temperature Range
Load Current
C EXT
http://onsemi.com
3
Rating
4.5 to 5.5
0 to +70
0 to 500
10 ± 10%
Units
V
° C
mA
m F
