参数资料
| 型号： | LTC3703IGN#PBF |
| 厂商： | Linear Technology |
| 文件页数： | 20/34页 |
| 文件大小： | 0K |
| 描述： | IC REG CTRLR BST PWM VM 16-SSOP |
| 标准包装： | 100 |
| PWM 型： | 电压模式 |
| 输出数： | 1 |
| 频率 - 最大： | 330kHz |
| 占空比： | 96% |
| 电源电压： | 9.3 V ~ 15 V |
| 降压： | 是 |
| 升压： | 是 |
| 回扫： | 无 |
| 反相： | 无 |
| 倍增器： | 无 |
| 除法器： | 无 |
| Cuk： | 无 |
| 隔离： | 无 |
| 工作温度： | -40°C ~ 125°C |
| 封装/外壳： | 16-SSOP（0.154"，3.90mm 宽） |
| 包装： | 管件 |
第1页第2页第3页第4页第5页第6页第7页第8页第9页第10页第11页第12页第13页第14页第15页第16页第17页第18页第19页当前第20页第21页第22页第23页第24页第25页第26页第27页第28页第29页第30页第31页第32页第33页第34页
LTC3703
APPLICATIONS INFORMATION
*2003 Linear Technology
*may require modifications for other
*MOSFETs
*inductor
rl out1 out 0.015
;inductor series R
cout out out2 540u
;capacitor value
*3703 internals
;3703multiplier
.ac dec 100 1k 1meg
.end
FeedbackComponentSelection
Selecting the R and C values for a typical Type 2 or
Type 3 loop is a nontrivial task. The applications shown
in this data sheet show typical values, optimized for the
power components shown. They should give acceptable
performance with similar power components, but can be
way off if even one major power component is changed
significantly. Applications that require optimized transient
response will require recalculation of the compensation
values specifically for the circuit in question. The underlying
mathematics are complex, but the component values can
be calculated in a straightforward manner if we know the
gain and phase of the modulator at the crossover frequency.
Modulator gain and phase can be measured directly from a
breadboard or can be simulated if the appropriate parasitic
values are known. Measurement will give more accurate
results, but simulation can often get close enough to give
a working system. To measure the modulator gain and
phase directly, wire up a breadboard with an LTC3703
and the actual MOSFETs, inductor and input and output
capacitors that the final design will use. This breadboard
should use appropriate construction techniques for high
speed analog circuitry: bypass capacitors located close
to the LTC3703, no long wires connecting components,
appropriately sized ground returns, etc. Wire the feedback
amplifier as a simple Type 1 loop, with a 10k resistor from
V OUT to FB and a 0.1μF feedback capacitor from COMP
to FB. Choose the bias resistor, R B , as required to set the
desired output voltage. Disconnect R B from ground and
connect it to a signal generator or to the source output
of a network analyzer to inject a test signal into the loop.
Measure the gain and phase from the COMP pin to the
output node at the positive terminal of the output capacitor.
Make sure the analyzer’s input is AC coupled so that the
DC voltages present at both the COMP and V OUT nodes
don’t corrupt the measurements or damage the analyzer.
If breadboard measurement is not practical, a SPICE
simulation can be used to generate approximate gain/
phase curves. Plug the expected capacitor, inductor and
MOSFET values into the following SPICE deck and gener-
ate an AC plot of V(V OUT )/V(COMP) in dB and phase of
V OUT in degrees. Refer to your SPICE manual for details
of how to generate this plot.
*3703 modulator gain/phase
*this file written to run with PSpice 8.0
SPICE simulators
rfet mod sw 0.02 ;MOSFET rdson
lext sw out1 10u ;inductor value
*output cap
resr out2 0 0.01 ;capacitor ESR
emod mod 0 value = {57*v(comp)}
vstim comp 0 0 ac 1 ;ac stimulus
.probe
With the gain/phase plot in hand, a loop crossover fre-
quency can be chosen. Usually the curves look something
like Figure 11. Choose the crossover frequency in the ris-
ing or flat parts of the phase curve, beyond the external
LC poles. Frequencies between 10kHz and 50kHz usually
work well. Note the gain (GAIN, in dB) and phase (PHASE,
in degrees) at this point. The desired feedback amplifier
gain will be –GAIN to make the loop gain at 0dB at this
frequency. Now calculate the needed phase boost, assum-
ing 60° as a target phase margin:
BOOST = –(PHASE + 30°)
If the required BOOST is less than 60°, a Type 2 loop can
be used successfully, saving two external components.
BOOST values greater than 60° usually require Type 3
loops for satisfactory performance.
3703fc
20
