2–4
Chapter 2: Getting Started
Design Flow
Simulate with the ModelSim Simulator
Altera provides a fixed testbench as an example in the simulation\testbench
directory. The testbench instantiates the design and tests the ASI operation. To use the
testbench with the ModelSim ? simulator, follow these steps:
1. In a text editor, open the simulation batch file,
simulation\modelsim\modelsim\asi_sim.bat , and edit it to point to your
installation of the ModelSim-Altera simulator.
2. Start the ModelSim-Altera simulator.
3. Run asi_sim.bat in the simulation\modelsim\modelsim directory. This file
compiles the design and starts the ModelSim-Altera simulator. A selection of
signals appears on the waveform viewer. The simulation runs automatically,
providing a pass/fail indication on completion.
Simulating in Third-Party Simulation Tools Using NativeLink
You can perform a simulation in a third-party simulation tool from within the
Quartus II software, using NativeLink.
Simulation Tools chapter in volume 3 of the Quartus II Handbook.
Altera provides a Quartus II project for use with NativeLink in the
ip\asi\simulation\quartus directory.
To set up simulation in the Quartus II software using NativeLink, follow these steps:
1. On the File menu click Open Project . Browse to the ip\asi\simulation\quartus
directory.
2. Open asi_sim.qpf .
3. Set up the Quartus II NativeLink.
a. On the Assignments menu, click Settings .
b. In the Category list, expand EDA Tool Settings and select Simulation .
c. In Tool name list, select a simulation tool.
1
Check that the absolute path to your third-party simulator executable is set.
On the Tools menu, click Options and select EDA Tools Options .
d. Under NativeLink settings , select Compile test bench and click Test Benches .
e. Click New in the Test Benches dialog box to create a testbench.
Asynchronous Serial Interface (ASI) MegaCore Function User Guide
January 2014 Altera Corporation
