5–12
AMON
Chapter 5: Testbench
Testbench Components Description
A value of one causes the model to generate data intended for a priority port, so that
Atlantic dav signal is ignored for all but the first transfer of a packet. A value of zero
causes the model to generate data intended for a data port, so dav is always obeyed.
defparam agen_dat_dut.PRIORITY=0;
defparam agen_pri_dut.PRIORITY=1;
– PORT_NAME
A string used to distinguish between verbose messages coming from multiple
instances of AGEN.
defparam agen_dat_dut.PORT_NAME = "AGEN_DAT_DUT";
defparam agen_pri_sis.PORT_NAME = "AGEN_PRI_SIS";
VHDL
The VHDL version of the AGEN module generates Atlantic data for the SerialLite II
demonstration testbench ( agen_dat_dut , agen_dat_sis ). The data generated is based
on an incrementing pattern.
The first element (at SOP) contains a decoded packet size for the packet. Once the
packet is transmitted, the packet size count increases by one for the next packet so that
successively larger packets are sent.
The AGEN generator sends packets until the internal packet count reaches the value
of the packets_to_end input integer. Inner packet gaps can be optionally enabled by
driving the ipg input to the module with a one. Doing so changes the behavior of the
Atlantic write enable so that it is controlled by the output of a pseudo random
generator. Verbose mode for the utility can be enabled by setting the verbose integer
in the generic map to one.
This testbench includes separate versions of the AMON module for Verilog HDL and
VHDL.
Verilog HDL
This Verilog HDL version of the AMON module monitors the Atlantic data received
(instances: amon_dat_dut , amon_pri_dut , amon_dat_sis , amon_pri_sis , and so on).
The data pattern received must be based on a LFSR that has produced a predictable
but non-incrementing pattern.
The AMON monitor does the following basic checks:
■
■
■
SerialLite II MegaCore Function
User Guide
Data checking: checks that the received data follows the LFSR pattern
id checking: checks that the packet identifier (first byte of each packet) is an
incrementing number.
Number of packets checking: checks that the expected number of regular data or
high priority packets have been received. The expected number of packets is set
via tasks.
January 2014 Altera Corporation
